Refurbished 2010 Ledwell DOT Stainless Steel (SS) Vacuum System

Tank Specifications-
3,000 Gallon Stainless Steel Tank
ASME/DOT 412 Vessel for hauling Hazardous Waste
"New" Data Plates
.375" Heads & .03125" Shell
13 lb. / Gallon Laden Weight / 39,000 lb. Payload
"New" air actuated isolation valve
"Re-Certified" 4" Girard SS relief valve
20" Manway located on top center of vacuum tank "New" 20" Manway Gasket & Wingbolt
Assemblies
Three (3) Stage, 20 Ton front hoist with Safety Prop
Hydraulically operated full opening rear door ("New" Rear Door Gasket)
Bolt in baffle welded to reinforcing pads
Rear Mounted liquid level indicator ("New" 6" SS Float Ball & Graphite Packing)
Primary Shut-Off, stainless steel float ball and cage inside tank ("New" SS Float Ball & Seat)
Two (2) Rear mounted hose hooks
Full length sub frame & hose trays
"Current" Cargo Tank Inspections (VIK)

Vacuum System- -
"Brand New" Fruitland RCF870 (512 CFM) vacuum pump, continuous duty vane pump, fan
cooled
Hydraulically driven with "New" Hydraulic Motor & Coupler
4 Way valve for vacuum loading / pressure offloading
"New" standard pressure relief and vacuum relief valves
"New" 4" Betts SS manual valve with SS kamlok fittings on intake
"New" 6" Betts SS self-closing valve with 4" SS manual ball valve with SS Kamlok fittings on discharge
"New" air switches (2) and hose for emergency shut-off and rear discharge valve.
Secondary Moisture Trap located on front driver side of vacuum tank. "New" 12" Manway Gasket, Ball Valve, Wingbolt Assemblies, SS Float Ball & Seat
Oil Catch Muffler located on front driver side sub-frame hose tray assembly. "New" Ball Valve on Drain and 4" Kamlok on Discharge(s)
"New" vacuum hoses with T-Bolt clamps

Hydraulic System -
"New" PTO & hydraulic pump direct mounted to transmission
"New" hydraulic heat exchanger with electric fan
40 Gallon hydraulic reservoir with shut-offs located on front sub-frame assembly "New"
Hydraulic Oil Sight Gauge Assembly
"New" 3-section spool valve; vacuum pump, dump hoist & rear door
"New" hydraulic hoses

Accessories -
Urethane paint
Painted "White" or "Customer Color"
"New" LED rear and side marker lights
"New" rear work lights and amber strobe
"New" junction box for electrical
DOT Rear Bumper connected to Vacuum System.
"New" four (4) numbered placards, "New" 25' static line and "New" steel toolbox assembly (18" x 18" x 36")

Chassis -

Complete system installed on "Brand New" 2025 Freightliner M2 106 Plus Chassis, basic truck
chassis specifications, include Cummins L9 350 HP Engine, Fuller 10 speed manual
transmission, 18,000 lb. front (Aluminum front wheels) and 40,000 lb. tandem rear axle with air
ride suspension (Steel rear wheels). California CARB.
